| 产品系列 P/N (Series) |
功率 Watt |
输入电压(VDC) Input Range |
输出类型 Output Type |
隔离电压 Isolated |
尺寸 Size(mm) |
封装形式 Package Style |
PDF 下载 |
|---|---|---|---|---|---|---|---|
GB10M
|
10W | 80-264VAC | Single | 4000VAC | 48.5×23.0×14.0 | DIL | 下载 |
GB5M
|
5W | 80-264VAC | Single | 4000VAC | 48.5×23.0×14.0 | DIL | 下载 |
GB5M
|
5W | 80-264VAC | Single | 4000VAC | 48.5×23.0×14.0 | DIL | 下载 |
GB003
|
3W | 90～264VAC | Single | 150VDC | 32.5×23.0×16.0 | DIL | 下载 |
GB005
|
5-6W | 90～264VAC | Single | 150VDC | 48.5×23.0×16.0 | DIL | 下载 |
GB015
|
15W | 90～264VAC | Single | 150VDC | 80.0×40.0×24.0 | DIL | 下载 |
GB020
|
20/30W | 90～264VAC | Single/Dual | 3000VDC | 101.6×50.8×31.0 | DIL | 下载 |
GB030
|
20/30W | 90～264VAC | Single/Dual | 3000VDC | 101.6×50.8×31.0 | DIL | 下载 |
GB040
|
40W | 90～264VAC | Dual/Triple | 3000VDC | 101.6×50.8×31.0 | DIL | 下载 |
GB40A
|
40/60W | 90～264VAC | Single | 1500VDC | 101.6×50.8×31.0 | DIL | 下载 |
GB60A
|
40/60W | 90～264VAC | Single | 1500VDC | 101.6×50.8×31.0 | DIL | 下载 |
GB100
|
100W | 90～264VAC | Single | 3000VDC | 127×76.2×35.56 | DIL | 下载 |
